Fujian Huamo Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of 8 inch fouling resistant ro membrane in China. If you're going to wholesale bulk 8 inch fouling resistant ro membrane made in China, welcome to get catalog and price list from our factory. All custom made products are with high quality and competitive price. Also, OEM service is available.
Product Details
The membrane features a large active area of 400 ft² (37 m²), enabling higher water production capacity and reducing the number of elements required in large-scale RO systems. It ensures stable performance even under challenging feedwater conditions. The optimized membrane surface further supports long-term operational stability and reduced cleaning frequency.
Technical Specifications
|
Parameter |
Value |
|
Model |
FR-8040 |
|
Active Membrane Area |
400 ft² (37 m²) |
|
Stabilized Salt Rejection |
99.6% |
|
Minimum Salt Rejection |
99.3% |
|
Permeate Flow Rate |
10,500 GPD (40 m³/d) |
|
Feed Pressure (Test) |
1.03 MPa (150 psi) |
|
Feed Temperature |
25°C (77°F) |
|
Feed Concentration |
5,000 ppm NaCl |
|
Feed pH |
8 |
|
Recovery Rate |
15% |
|
Maximum Operating Pressure |
41 bar (600 psi) |
|
Maximum Operating Temperature |
45°C (113°F) |
|
Maximum Pressure Drop |
1.0 bar (15 psi) |
|
pH Range (Continuous Operation) |
2–11 |
|
pH Range (Chemical Cleaning) |
1–13 |
|
Maximum Feed SDI15 |
5.0 |
|
Free Chlorine Tolerance |
<0.1 ppm |
|
Length (A) |
1,016 mm (40 in.) |
|
Diameter (D) |
201 mm (7.95 in.) |
|
Permeate Tube Diameter (B) |
26.7 mm (1.05 in.) |
|
O-Ring Diameter (C) |
29 mm (1.125 in.) |
|
Weight |
17.5 kg |
Membrane Performance
The FR-8040 membrane is developed for medium and large-scale RO systems requiring both fouling resistance and high production capacity. Under standard test conditions, it delivers 10,500 GPD (40 m³/d) permeate flow while maintaining a stabilized salt rejection of 99.6%.
Its fouling-resistant membrane structure helps support stable operation in applications where feed water quality may increase the risk of membrane contamination.
Applications
- Wastewater recycling projects
- Commercial reverse osmosis systems
- Food and beverage water treatment
- Process water production
- Pretreated surface water desalination systems
FAQ
Q1.What is the salt rejection rate of the FR-8040 membrane? What after‑sales services do you provide beyond standard support?
A:We offer a "full‑lifecycle response" service package.
Q2.What special packaging and shipping guarantees do you offer?
A:We use double moisture‑proof sealing + inert gas protection to keep the membrane elements wet during long-distance sea or land transport.
Q3.What feed water sources can this membrane handle?
A:The membrane is commonly used with municipal water, surface water, reclaimed water, pretreated wastewater, and industrial process water with moderate fouling potential.
Q4.How often should the membrane be cleaned?
A:Cleaning frequency depends on feed water quality and operating conditions. Monitoring permeate flow, differential pressure, and salt rejection can help determine the appropriate cleaning schedule.
