Fujian Huamo Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of high pressure anti fouling ro membrane in China. If you're going to wholesale bulk high pressure anti fouling ro membrane made in China, welcome to get catalog and price list from our factory. All custom made products are with high quality and competitive price. Also, OEM service is available.
Product Details
The 8040 RO membrane is engineered for high-pressure operation in industrial and municipal water treatment systems, delivering reliable performance under demanding conditions. It is widely used in power plant boiler feedwater applications to ensure continuous and stable water supply. In petrochemical and chemical industries, it provides strong fouling resistance against organic compounds, colloids, and suspended solids. It is also suitable for food, beverage, and pharmaceutical production where consistent permeate quality is critical. The optimized membrane surface reduces fouling tendency and pressure drop, supporting efficient operation under complex feedwater conditions. Across municipal and industrial pure water systems, it ensures long service life, stable output, and reduced maintenance requirements.
Technical Specifications
|
Parameter |
Value |
|
Model |
FR4040 |
|
Active Membrane Area |
78 ft² (7.2 m²) |
|
Stabilized Salt Rejection |
99.3% |
|
Minimum Salt Rejection |
99.0% |
|
Permeate Flow Rate |
2250 GPD (8.7 m³/d) |
|
Feed Pressure (Test) |
1.03 MPa (150 psi) |
|
Feed Temperature |
25°C (77°F) |
|
Feed Concentration |
1,500 ppm NaCl |
|
Feed pH |
8 |
|
Recovery Rate |
15% |
|
Maximum Operating Pressure |
41 bar (600 psi) |
|
Maximum Operating Temperature |
45°C (113°F) |
|
Maximum Pressure Drop |
1.0 bar (15 psi) |
|
pH Range (Continuous Operation) |
2–11 |
|
pH Range (Chemical Cleaning) |
1–13 |
|
Maximum Feed SDI15 |
5.0 |
|
Free Chlorine Tolerance |
<0.1 ppm |
|
Length |
1,016 mm (40 in.) |
|
Diameter |
201 mm (7.95 in.) |
|
Weight |
3.38 kg |
Notes
* Never allow back‑pressure on the permeate side, as it may cause irreversible damage to the membrane elements.
* All permeate (and concentrate) produced during the first hour of operation should be drained and not used. Water quality and performance typically stabilise after about 1 hour of operation.
Membrane Performance
The High Pressure Anti Fouling RO Membrane is developed for applications requiring both fouling resistance and pressure tolerance.
The membrane is suitable for systems where higher operating pressures are necessary to maintain production targets while treating water sources with elevated fouling potential.
Applications
- High-pressure water treatment systems
- Surface water purification
- Process water production
- Food and beverage manufacturing
- Chemical industry water treatment
- Industrial wastewater recycling
FAQ
Q1. What makes this membrane suitable for high-pressure RO systems?
A:The membrane is designed to operate at pressures up to 41 bar (600 psi), making it suitable for industrial reverse osmosis systems that require stable performance under elevated operating pressures.
Q2. Do you offer OEM and private label services?
A:Yes. OEM manufacturing, customized packaging, and private branding services are available for distributors and equipment manufacturers.
Q3.What industries commonly use this membrane?
A:Typical applications include power generation, food and beverage production, wastewater reuse, electronics manufacturing, pharmaceutical water treatment, and industrial process water systems.
