Fujian Huamo Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of mini ro edi system in China. If you're going to wholesale bulk mini ro edi system made in China, welcome to get catalog and price list from our factory. All custom made products are with high quality and competitive price. Also, OEM service is available.
Product Details
Mini RO EDI system combines membrane filtration and continuous electro-demineralization within a dual-stage package designed to fit within compact equipment enclosures, processing feed water continuously without the downtime associated with traditional resin tank changeouts. Engineered for low-flow applications requiring output capacities from 50 L/H to 300 L/H to optimize water and energy use, this specific mini RO EDI system delivers a consistent output water resistivity range of 10-18.2 MΩ·cm to meet strict multi-industry reagent and cleanroom rinse standards. The hardware features integrated low-voltage power supplies with automated current controls matched to the small-scale deionization components to maximize ion rejection while minimizing thermal generation, and it is built with premium, corrosion-resistant materials to ensure a stable operational lifecycle of approximately 4 years under standard usage guidelines.
Product Specifications
|
Parameter |
KLX-50L |
KLX-100L |
KLX-150L |
KLX-200L |
KLX-250L |
KLX-300L |
|
Module Flow (L/H) |
50 |
100 |
150 |
200 |
250 |
300 |
|
Recovery Rate (%) |
75-85% |
75-85% |
75-85% |
75-85% |
75-85% |
75-85% |
|
Product Stream Adjust (L/H) |
50 |
100 |
150 |
200 |
250 |
300 |
|
Concentrate Stream Adjust (L/H) |
10 |
20 |
30 |
40 |
50 |
60 |
|
Operating Current (A) |
0-2 |
0-2 |
0-2 |
0-2 |
0-2 |
0-2 |
|
Feed Water Source |
RO Permeate / Product Water (Two-Stage RO Recommended) |
|||||
|
Feed Water Conductivity (µS/cm) |
1-10 (Maximum Entry ≤ 25) |
|||||
|
Feed Water Temperature (°C) |
5 - 35 (Optimal Operating Performance at 25°C) |
|||||
|
Product Water Resistivity (MΩ·cm) |
10 - 18.2 |
|||||
Technical Advantages & Brand Capabilities
Why Partner With Our Enterprise?
1. Single-Source Technical Engineering Support for mini RO EDI system: We provide full design integration, including matching booster pumps, pre-filtration cartography, and custom automation interfaces.
2. Targeted Component Restoration & Diagnostic Services: Our engineering facility specializes in diagnostic testing for compact multi-stage assemblies, using specialized chemical flushes to clean scaled or fouled components.
3. Rigid Quality Control Protocols: Every integrated system undergoes thorough pressure holding tests and multi-hour fluid analysis to guarantee performance before final dispatch.
Frequently Asked Questions (FAQ)
Q1: Can this system run on standard municipal tap water?
A1: Yes, provided appropriate pre-treatment (such as a carbon filter and water softener) is installed upstream to protect the integrated RO membrane from chlorine and hardness fouling.
Q2: What are the consequences of an unexpected water supply interruption?
A2: If water flow stops while the current remains active, the internal elements can sustain severe thermal damage. The system includes built-in flow switches to automatically cut off power if flow stops.
Q3: What is the expected lifespan of the core modules?
A3: With regular maintenance and timely pre-filter changes, the core purification assembly provides an active service life of approximately 4 years.
