Fujian Huamo Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of compact edi water treatment system in China. If you're going to wholesale bulk compact edi water treatment system made in China, welcome to get catalog and price list from our factory. All custom made products are with high quality and competitive price. Also, OEM service is available.
Product Details
Compact EDI water treatment system delivers turnkey pure water production on a single skid framework, combining pre-treatment filtration and electroionization to consistently provide high-purity water without chemical handling in tight facility layouts. Sized for low-flow operations requiring processing flows from 50 L/H to 300 L/H to optimize space usage, this specialized compact EDI water treatment system maintains a stable product water resistivity range of 10-18.2 MΩ·cm to meet precise specifications for electronics rinsing, boiler feeds, and chemical processing. The platform features integrated, pre-wired process instrumentation-including digital flow sensors, conductivity meters, and automated current controllers-and is built on a heavy-duty, corrosion-resistant frame that provides a reliable service life of approximately 4 years under specified operating conditions.
Product Specifications
|
Module Flow (L/H) |
50 |
100 |
150 |
200 |
250 |
300 |
|
Recovery Rate (%) |
75-85% |
75-85% |
75-85% |
75-85% |
75-85% |
75-85% |
|
Product Stream Adjust (L/H) |
50 |
100 |
150 |
200 |
250 |
300 |
|
Concentrate Stream Adjust (L/H) |
10 |
20 |
30 |
40 |
50 |
60 |
|
Operating Current (A) |
0-2 |
0-2 |
0-2 |
0-2 |
0-2 |
0-2 |
|
Feed Water Source |
RO Permeate / Product Water (Two-Stage RO Recommended) |
|||||
|
Feed Water Conductivity (µS/cm) |
1-10 (Maximum Entry ≤ 25) |
|||||
|
Feed Water Temperature (°C) |
5 - 35 (Optimal Operating Performance at 25°C) |
|||||
|
Product Water Resistivity (MΩ·cm) |
10 - 18.2 |
|||||
Technical Advantages & Brand Capabilities
Why Partner With Our Enterprise?
1. Single-Source Technical Engineering Support: We manage the complete engineering lifecycle, from initial system sizing and piping schematics to PLC automation programming and onsite start-up assistance.
2. Targeted Component Restoration & Diagnostic Services: Our service center provides comprehensive diagnostics for equipment experiencing mineral scaling or resin exhaustion, offering targeted chemical flushes to restore factory specs.
3. Rigid Quality Control Protocols: Every completed compact EDI water treatment system undergoes factory acceptance testing (FAT), including full wet-testing and electrical validation, before delivery.
Frequently Asked Questions (FAQ)
Q1: What pre-treatment is included in this system?
A1: The system typically includes carbon filtration, water softening, and a single or double-pass reverse osmosis system to ensure feed water remains within 1-10 µS/cm.
Q2: How does the system handle dissolved carbon dioxide (CO2)?
A2: Dissolved CO2 can significantly lower the final water resistivity. If inlet levels are high, an upstream membrane degasifier or pH adjustment dosing loop should be added.
Q3: What is the typical wastewater rate?
A3: The system operates at a high water recovery rate of 75% to 85%, meaning only 15% to 25% of the total feed flow is sent to the drain as clean concentrate.
