Fujian Huamo Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of small edi module in China. If you're going to wholesale bulk small edi module made in China, welcome to get catalog and price list from our factory. All custom made products are with high quality and competitive price. Also, OEM service is available.
Product Details
- Small EDI Module Delivers Continuous Operation Without Standby Regeneration: Driven by a DC electric field, the module transfers ions out of the feed stream while simultaneously splitting water into H+ and OH- ions. This mechanism provides continuous, on-line regeneration of the resin bed, maintaining steady production cycles without chemical downtime.
- Stable Output Quality from Small EDI Module: Consistently yields high-purity product water with a typical resistivity range of 10-18.2 MΩ·cm, meeting precise multi-industry specifications.
- Compact Low-Flow Configuration: Engineered specifically for small-scale pure water installations (ranging from 50 L/H to 300 L/H), minimizing physical footprint requirements and simplifying overall system integration.
- Modular Integration Layout: Standard individual configurations support flows from 0.05 m³/h to 0.3 m³/h, allowing parallel arrangements to fulfill expanded volumetric scale requirements seamlessly.
- Operational Service Life: Built with robust grounding mechanisms and structural sealing, achieving a typical active field life of approximately 4 years under compliant feed conditions.
Product Specifications
|
Parameter |
KLX-50L |
KLX-100L |
KLX-150L |
KLX-200L |
KLX-250L |
KLX-300L |
|
Module Flow (L/H) |
50 |
100 |
150 |
200 |
250 |
300 |
|
Recovery Rate (%) |
75-85% |
75-85% |
75-85% |
75-85% |
75-85% |
75-85% |
|
Product Stream Adjust (L/H) |
50 |
100 |
150 |
200 |
250 |
300 |
|
Concentrate Stream Adjust (L/H) |
10 |
20 |
30 |
40 |
50 |
60 |
|
Operating Current (A) |
0-2 |
0-2 |
0-2 |
0-2 |
0-2 |
0-2 |
|
Feed Water Source |
RO Permeate / Product Water (Two-Stage RO Recommended) |
|||||
|
Feed Water Conductivity (µS/cm) |
1-10 (Maximum Entry ≤ 25) |
|||||
|
Feed Water Temperature (°C) |
5 - 35 (Optimal Operating Performance at 25°C) |
|||||
|
Product Water Resistivity (MΩ·cm) |
10 - 18.2 |
|||||
Technical Advantages & Brand Capabilities
Why Partner With Our Enterprise?
1. Single-Source Technical Engineering Support for Small EDI Module: We provide systematic coverage extending from component design and manufacturing to initial setup, onsite calibration, and long-term maintenance infrastructure.
2. Targeted Component Restoration & Diagnostic Services: We perform technical evaluation and structural diagnostics for standard industrial brands-addressing localized internal burning, heavy mineral scaling, and internal membrane breach issues to extend system field operations.
3. Rigid Quality Control Protocols: Every single unit undergoes pressure boundary retention testing and electrical baseline calibration prior to dispatch, ensuring robust mechanical linkages and stable environmental seals.
Frequently Asked Questions (FAQ)
Q1: Is OEM customization available for these systems?
A1: Yes. We maintain in-house component manufacturing capabilities and PLC program layout control. This allows us to modify specific hardware dimensions, connection arrangements, and output parameters to fit client system designs.
Q2: Is a Reverse Osmosis (RO) system mandatory before this step?
A2: Yes. The input stream conductivity must reside between 1-10 µS/cm. Deploying adequate pre-treatment systems (such as single or two-stage RO, softeners, and degasifiers) protects the internal components from premature fouling and minimizes maintenance intervals.
Q3: What are the consequences of an abrupt water supply interruption?
A3: Active electrical operations generate heat. If the fluid flow drops to zero while the DC power grid remains active, the internal elements can sustain immediate, irreversible thermal destruction. Integrated systems must include automated power cut-offs linked to flow verification switches.
Q4: What steps should be taken if the product water resistivity drops below 15 MΩ·cm?
A4: First, verify that the operating DC current corresponds to the recommended operating window. Second, evaluate the carbon dioxide (CO2) load in the feed water. Elevated levels of dissolved CO2 present an ambient ionic load that drops the final resistivity of the output water stream.
Q5: What is the expected service lifecycle of these small-scale systems?
A5: Given stable pre-treatment conditions, compliant feed water profiles, and adherence to regular operational guidelines, these units maintain an active functional timeline of approximately 4 years.
