Fujian Huamo Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of nanofiltration membrane element in China. If you're going to wholesale bulk nanofiltration membrane element made in China, welcome to get catalog and price list from our factory. All custom made products are with high quality and competitive price. Also, OEM service is available.
Product Details
The nanofiltration membrane element combines advanced thin-film composite membrane technology with optimized feed channel design to achieve efficient separation performance across a wide range of industrial applications. it delivers stable separation performance, high permeate productivity, and lower operating pressure requirements, helping reduce energy consumption and overall system operating costs.
Product Specifications
The nanofiltration membrane element is designed for industrial water treatment systems requiring efficient organic removal, hardness reduction, and partial desalination.
|
Parameter |
Specification |
|
Membrane Type |
Thin Film Composite Polyamide |
|
Separation Technology |
Nanofiltration |
|
Available Sizes |
4040 8040 |
|
Operating Pressure |
4 – 10 bar |
|
Maximum Operating Temperature |
45°C |
|
Recommended Operating Temperature |
5 – 45°C |
|
Salt Rejection |
50% – 80% |
|
Recovery Rate |
Up to 75% |
|
pH Range (Operation) |
4 – 10 |
|
pH Range (Cleaning) |
2 – 11 |
|
Organic Removal Efficiency |
High |
|
Hardness Removal |
Excellent |
|
Chemical Stability |
High |
|
Fouling Resistance |
Enhanced Anti-Fouling Design |
|
Application Water Sources |
Groundwater, Surface Water, Municipal Water, Process Water, Wastewater Reuse |
Available Industrial Configurations
|
Model |
Diameter |
Length |
Membrane Area |
|
NF-4040 |
4 inch |
40 inch |
Customized |
|
NF-8040 |
8 inch |
40 inch |
Customized |
|
Custom Design |
Available |
Available |
Available |
Key Features
- Selective separation of hardness ions
- Removal of organic matter and color compounds
- Stable low-pressure operation
- High recovery and energy efficiency
- Wide application adaptability
Technical Highlights
- Operating pressure: 4–10 bar
- Temperature: 5–45°C
- pH range: 4–10 (cleaning 2–11)
- Salt rejection: 50%–80%
- High chemical stability
Application Scope
- Industrial water treatment systems
- Municipal water purification
- Process water conditioning
- Wastewater reuse projects
- Pre-treatment for RO systems
Why Choose Our Nanofiltration Membrane Element
- Mature membrane manufacturing technology
- Strict quality control and testing process
- Stable global supply capability
- OEM/private label support available
